Especificaciones técnicas
Rims
Wheel Size / ETRTO
29"/ 622 mm
Tubeless Compatibility
Yes
Insert Compatibility
Yes
Brake Compatibility
Disc (Centerlock)
Rim Construction
Carbon Clincher Mini Hooked
Valve Stem Length
Roval Tubeless Valve, Alloy 34mm
Hole Count
20H
Rear Rim Dimensions
Depth: 26mm, External Width: 36.5mm, Internal Width: 28.5mm, Bead Hook Width: 4mm
Rear Rim
Control World Cup Carbon 29" (WC042)
Front Rim Dimensions
Depth: 26mm, External Width: 36.5mm, Internal Width: 28.5mm, Bead Hook Width: 4mm
Front Rim
Control World Cup Carbon 29" (WC042)
Hubs
Rear Hub
Roval Low Flange Mountain Hub , Center Lock, 12x148mm (LFM24)
Rear Freehub Body
DT Swiss Ratchet EXP (36T ): Sram XD
Rear Hub Bearing
DT Sinc Ceramic Bearings - DS:1526 (15 x 26 x 7 mm), NDS: 6802 (15 x 24 x 5 mm)
Front Hub
Roval Low Flange Mountain Hub, Center Lock, 15x110mm, 19mm OD End Caps Installed (LFM23)
Front Hub Bearing
DT Sinc Ceramic Bearings - DS: 6802 (15 x 24 x 5 mm), NDS: 6802 (15 x 24 x 5 mm)
Spokes & nipples
Nipples
VONOA Internal Carbon Spoke Nipple, Alloy, 8.1mm
Rear Spokes
Custom Tuned for Roval, Vonoa Carbon w/Ti End Pcs: Straigh-Pull, 20qty
Rear Lacing Pattern
Two-cross/Two-cross (1:1)
Front Spokes
Custom Tuned for Roval, Vonoa Carbon w/Ti End Pcs: Straigh-Pull, 20qty
Front Lacing Pattern
Two-cross/Two-cross (1:1)
Tire info
Tubeless Tape Width
30mm
Tire Type
Tubeless, Tube Type Clincher
Design Tire
Specialized Air Trak 29x2.35 Flex Lite
Max Pressure
Tubeless 40psi , Tubed 40psi
Approved Tire Widths
1.9-2.6
Weight
Wheelset Weight
998g (with valves and tape)
Rear Weight
546g (with valves and tape)
Front Weight
452g (with valves and tape)
General
Warranty
Limited Lifetime Warranty
Assembly Method
Hand Built
Weight Limit
275 lbs. / 125 kg.
E-bike Approved
No
Extras
Roval Single Wheel Bag, 4 Extra Spokes and Nipples, 31mm OD End Caps, 2 sets of Roval Decal Stickers (Liquid Silver, Metallic White)
